ICON 2024-2025 Toyota Tacoma 1.25-3" Lift, Stage 3 Suspension System, Tubular

The ICON 2024-2025 Toyota Tacoma Stage 3 Tubular Suspension system is a complete front and rear-end upgrade for Tacoma owners who want improved wheel travel, front-end geometry correction, and better rear damping in a single well-matched package without the triple-rate or overland rear spring configurations of the higher-tier Stage 3 variants. This system pairs vehicle-specific-tuned 2.5 Series internal-reservoir front coilovers with tubular upper control arms featuring Delta Joint PRO and matches the front to ICON 2.0 Aluminum Series remote-reservoir rear shocks for a balanced and capable suspension tune on the 2024 and 2025 Tacoma platform.

ICON 2024-2025 Toyota Tacoma Stage 3 Tubular Suspension UCAs With Delta Joint PRO

The tubular upper control arms in this system are designed to correct the front-end geometry changes that lifting the 2024 and 2025 Tacomas creates, adding caster correction and improving suspension component clearance at full travel. Each UCA features ICON's patented Delta Joint PRO with 90 degrees of total articulation, replacing the OE ball joint to allow full bump and droop travel without bind through the complete range of suspension movement. The Delta Joint PRO is fully serviceable and rebuildable, giving you the ability to refresh the joint as needed without replacing the entire control arm.

2.5 Series Internal Reservoir Coilovers for Front Performance

Up front, this system uses ICON 2.5 Series coilovers with internal reservoirs and vehicle-specific tuned coil springs. The internal reservoir provides excellent heat management during sustained off-road use, keeping damper performance consistent through conditions where standard shocks would begin to show fade. Front lift is adjustable from 1.25 to 3 inches over stock, creating the clearance needed for larger and more aggressive wheel and tire setups. Corrosion-resistant CAD-plated coilover bodies with 7/8 inch shafts and FK rod end bearings add long-term durability and minimal deflection under load throughout the system.

Front Differential Drop Kit for CV Angle Correction on 4WD Models

For 4WD Tacoma models, the front differential drop kit works alongside ICON's Tacoma-specific coilover lengths to improve CV operating angles and maximize usable front suspension travel after the lift is installed. Polyurethane differential mounting bushings replace the softer OE units to limit differential movement under load and improve driveline stability during hard use on the trail and on the street.

2.0 Aluminum Series Remote Reservoir Rear Shocks for Balanced Rear Performance

The rear of this Stage 3 Tubular system uses ICON 2.0 Aluminum Series remote reservoir rear shocks with 5/8 inch shafts and vehicle-specific valving that balances the rear of the Tacoma with the front coilover tune. These shocks are compatible with 0 to 1 inch of rear lift over stock and provide enhanced cooling through the remote reservoir design for consistent rear damping performance during hard off-road use. The result is a Tacoma that rides smoother, tracks straighter, and handles more confidently on pavement and dirt alike.

Important Application Notes

This kit is configured for 4WD Tacoma models. On 2WD models, the differential drop is not required, and remaining components can be purchased individually. This system is not compatible with Adaptive Variable Suspension-equipped Tacomas or submodels with rear leaf springs. ADAS recalibration is required after installation. Added accessory weight will alter the final lift range from stock-based measurements.

System Components

Product Details

Who This System Is For

The ICON 2024-2025 Toyota Tacoma Stage 3 Tubular Suspension is the right choice for Tacoma owners who want a complete suspension upgrade with tubular UCA geometry correction, internal reservoir front coilovers, and remote reservoir rear shocks in a straightforward matched package. With adjustable front lift from 1.25 to 3 inches and Delta Joint PRO articulation, this system gives the 2024 and 2025 Tacoma meaningful performance gains over stock for daily driving and trail use without the added complexity of overland or triple-rate rear spring configurations.

Have questions about fitment, installation, or product selection? Get in touch with IMM Hawaii Parts, and our team will be happy to help.
